Semantic Diff

The semantic diff compares two versions of an Effect program at the IR level, not the text level. It reports structural changes (steps added, removed, moved, or renamed) giving you a meaningful view of what changed in the program’s behavior.

This is especially useful when reviewing AI-generated code where the text diff can be large and hard to follow, but the structural change may be quite targeted.

Worked Example: Reviewing an AI Agent’s PR

An AI coding agent was asked to “make the payment flow production-ready.” The resulting PR touches 40+ lines across services, error types, and the main workflow. A text diff is noisy. The semantic diff tells you exactly what changed structurally.

The before: a working MVP

send-money-before.ts

// Services: TransferValidation, ExchangeRates, Accounts, Transfers

export const sendMoney = (input: TransferRequest) =>
  Effect.gen(function* () {
    const validation = yield* TransferValidation;
    const rates = yield* ExchangeRates;
    const accounts = yield* Accounts;
    const transfers = yield* Transfers;

    const validated = yield* validation.validate(input);
    const rate = yield* rates.getRate(validated.fromCurrency, validated.toCurrency);
    const balance = yield* accounts.getBalance(validated.senderId);

    if (balance < validated.amount) {
      return yield* Effect.fail(
        new InsufficientFundsError(balance, validated.amount),
      );
    }

    const convertedAmount = Math.round(validated.amount * rate * 100) / 100;

    const transfer = yield* transfers.execute({
      recipientIban: validated.recipientIban,
      amount: convertedAmount,
      currency: validated.toCurrency,
    });

    return { transferId: transfer.transferId, convertedAmount, rate };
  });

Railway diagram (before):

flowchart LR
  A[validation <- TransferValidation] -->|ok| B[rates <- ExchangeRates]
  B -->|ok| C[accounts <- Accounts]
  C -->|ok| D[transfers <- Transfers]
  D -->|ok| E[rate <- rates.getRate]
  E -->|ok| F[balance <- accounts.getBalance]
  F -->|ok| G{balance < amount?}
  G -->|ok| H[transfers.execute]
  H -->|ok| Done((Success))
  E -->|err| EE([RateUnavailable])
  G -->|err| GE([InsufficientFunds])
  H -->|err| HE([TransferRejected])

The after: AI-generated “production-ready” version

The AI agent added:

• FraudScreening service, screens every transfer before execution
• Notifications service, sends a confirmation after success
• Retry with exponential backoff on transfers.execute
• New error types: FraudRiskError, ConfirmationFailedError

send-money-after.ts

export const sendMoney = (input: TransferRequest) =>
  Effect.gen(function* () {
    const validation = yield* TransferValidation;
    const rates = yield* ExchangeRates;
    const accounts = yield* Accounts;
    const fraud = yield* FraudScreening;        // NEW
    const transfers = yield* Transfers;
    const notifications = yield* Notifications;  // NEW

    const validated = yield* validation.validate(input);
    yield* fraud.screen(validated);              // NEW
    const rate = yield* rates.getRate(validated.fromCurrency, validated.toCurrency);
    const balance = yield* accounts.getBalance(validated.senderId);

    if (balance < validated.amount) {
      return yield* Effect.fail(
        new InsufficientFundsError(balance, validated.amount),
      );
    }

    const convertedAmount = Math.round(validated.amount * rate * 100) / 100;

    const transfer = yield* transfers.execute({  // CHANGED: now has retry
      recipientIban: validated.recipientIban,
      amount: convertedAmount,
      currency: validated.toCurrency,
    }).pipe(
      Effect.retry(
        Schedule.exponential('200 millis').pipe(
          Schedule.intersect(Schedule.recurs(2)),
        ),
      ),
    );

    yield* notifications.sendConfirmation({      // NEW
      transferId: transfer.transferId,
      amount: convertedAmount,
      currency: validated.toCurrency,
    });

    return { transferId: transfer.transferId, convertedAmount, rate };
  });

Railway diagram (after):

flowchart LR
  A[validation <- TransferValidation] -->|ok| B[rates <- ExchangeRates]
  B -->|ok| C[accounts <- Accounts]
  C -->|ok| D[fraud <- FraudScreening]
  D -->|ok| E[transfers <- Transfers]
  E -->|ok| F[notifications <- Notifications]
  F -->|ok| G[fraud.screen]
  G -->|ok| H[rate <- rates.getRate]
  H -->|ok| I[balance <- accounts.getBalance]
  I -->|ok| J{balance < amount?}
  J -->|ok| K["transfers.execute + retry"]
  K -->|ok| L[notifications.sendConfirmation]
  L -->|ok| Done((Success))
  G -->|err| GE([FraudRisk])
  H -->|err| HE([RateUnavailable])
  J -->|err| JE([InsufficientFunds])
  K -->|err| KE([TransferRejected])
  L -->|err| LE([ConfirmationFailed])

Running the diff

The two fixture files live in the repo. Run the diff with:

npx effect-analyze \
  src/__fixtures__/docs/send-money-before.ts \
  src/__fixtures__/docs/send-money-after.ts \
  --diff

Diff output (markdown)

# Effect Program Diff: sendMoney → sendMoney

## Summary

| Metric | Count |
|--------|-------|
| Added | 8 |
| Removed | 1 |
| Renamed | 0 |
| Moved | 0 |
| Unchanged | 7 |
| Structural changes | 1 |

## Step Changes

- transfers.execute (removed)
+ FraudScreening (added)
+ Notifications (added)
+ fraud.screen (added)
+ transfers.execute(...).pipe (added)
+ notifications.sendConfirmation (added)
+ Effect.retry (added)
+ Schedule.exponential (added)

## Structural Changes

- + retry block added

## Added program: FraudScreening
## Added program: Notifications

What a reviewer learns in 10 seconds

1. 7 unchanged steps: the core flow (validate, get rate, check balance, fail path) is untouched
2. 1 removed step (transfers.execute): replaced by the .pipe(Effect.retry(...)) variant
3. 2 new service dependencies: FraudScreening and Notifications are new blast radius
4. 1 structural change: a retry block was added (exponential backoff on the transfer)
5. New error surface: the railway diagram shows FraudRisk and ConfirmationFailed as new error branches

Key reviewer question

The AI added notifications.sendConfirmation after the transfer succeeds but without error handling on the notification itself. A ConfirmationFailedError would propagate up and fail the entire workflow even though the money was already sent. Is that intentional?

This is the kind of question the semantic diff makes obvious. The structural view shows the notification step sits on the happy path with no catchTag around it.

Basic Usage

Compare the current file with the last commit:

npx effect-analyze HEAD:src/transfer.ts src/transfer.ts --diff

Single-File Shorthand

With a single argument and --diff, the analyzer compares HEAD against the working copy:

npx effect-analyze src/transfer.ts --diff

This is equivalent to HEAD:src/transfer.ts src/transfer.ts --diff.

Git Ref Syntax

Use any git ref with the ref:path syntax:

# Compare two branches
npx effect-analyze main:src/transfer.ts feature:src/transfer.ts --diff

# Compare specific commits
npx effect-analyze abc123:src/transfer.ts def456:src/transfer.ts --diff

# Compare a tag with the working copy
npx effect-analyze v1.0.0:src/transfer.ts src/transfer.ts --diff

What the Diff Detects

The diff engine classifies every step in both versions:

Change Type	Description	Example
Unchanged	Step exists in both versions with the same structure	validation.validate stayed the same
Added	Step exists only in the new version	fraud.screen is new
Removed	Step exists only in the old version	transfers.execute was replaced
Moved	Step exists in both but in a different structural container	A step moved from sequential into Effect.all
Renamed	Same callee but different binding name	const result → const transfer

Beyond individual steps, the diff also reports:

• Structural changes: new or removed retry, parallel, race, error-handler blocks
• Added programs: entirely new Effect programs in the file
• Removed programs: Effect programs that no longer exist

Output Formats

Markdown (default)

npx effect-analyze before.ts after.ts --diff

Produces a structured report with a summary table, step changes as a diff block, and structural changes. Best for human review and pasting into PR comments.

JSON

npx effect-analyze before.ts after.ts --diff --format json

Machine-readable diff object for CI integration. Each step has a kind field (added, removed, unchanged, moved, renamed) and metadata like callee, containerBefore, containerAfter.

{
  "beforeName": "sendMoney",
  "afterName": "sendMoney",
  "steps": [
    { "kind": "unchanged", "callee": "TransferValidation" },
    { "kind": "unchanged", "callee": "ExchangeRates" },
    { "kind": "unchanged", "callee": "Accounts" },
    { "kind": "added", "callee": "FraudScreening" },
    { "kind": "removed", "callee": "transfers.execute" },
    { "kind": "added", "callee": "fraud.screen" },
    { "kind": "added", "callee": "notifications.sendConfirmation" }
  ],
  "structuralChanges": [
    { "kind": "added", "nodeType": "retry" }
  ],
  "summary": {
    "added": 8, "removed": 1, "unchanged": 7,
    "structuralChanges": 1, "hasRegressions": false
  }
}

Mermaid

npx effect-analyze before.ts after.ts --diff --format mermaid

Renders the “after” program as a flowchart with color-coded nodes: green for added, yellow for moved, blue for renamed, and red dashed for removed steps (with --show-removed).

Regression Mode

Flag removed steps as regressions. Useful in CI to catch when an AI agent accidentally deletes error handling or removes a service call:

npx effect-analyze HEAD:src/transfer.ts src/transfer.ts --diff --regression

In regression mode, the summary includes a hasRegressions flag set to true if any step or structural block was removed. Combine with --format json to parse in CI:

# Fail the build if the AI removed any steps
DIFF=$(npx effect-analyze HEAD:src/transfer.ts src/transfer.ts --diff --regression --format json)
if echo "$DIFF" | jq -e '.[0].summary.hasRegressions' > /dev/null 2>&1; then
  echo "REGRESSION: Steps were removed from the Effect program"
  exit 1
fi

Watch for AI agents removing error handling

A common pattern with AI-generated refactors is simplifying code by removing catchTag, retry, or timeout wrappers. Regression mode catches this as a structural removal. Use it in CI to require human approval when structural blocks are deleted.

Programmatic Usage

import { analyze, diffPrograms, renderDiffMarkdown } from "effect-analyzer"
import { Effect } from "effect"

const before = await Effect.runPromise(analyze("./old-version.ts").single())
const after = await Effect.runPromise(analyze("./new-version.ts").single())

const diff = diffPrograms(before, after)
const report = renderDiffMarkdown(diff)

console.log(report)

Additional rendering functions:

import { renderDiffJSON, renderDiffMermaid } from "effect-analyzer"

// JSON output for CI
const json = renderDiffJSON(diff)

// Mermaid diagram with change highlights
const mermaid = renderDiffMermaid(diff)

Note

The diff operates on the IR structure, not on raw text. Two programs with identical source but different tsconfig settings may produce unexpected diffs. In practice this is rare.
